Continuous current: 120A; Max. short-term current: 200A; BEC voltage: 6V / 2A; Number of LiPo cells: 1-2; Number of NiCd/NiMH cells: 3-6; Resistance: 0.0003 Ohm; Weight: 105g; Dimensions: 43x36x33mm

Features:

• Designed for BL motors with and without sensor

• Controller continues to work if the sensor signal is interrupted

• Clean start-up and linear control behavior

• Clocked BEC for high loads

• 10 integrated, freely programmable profile memories

• The firmware can be updated via the USB port

• Simple programming using a button, alternatively the controller can be programmed using the program card or the program LCD box

• Compatible with mechanical brake systems

• Easily accessible, external connection for programming box

• Integrated data logger for motor speed and motor & controller temperature

• Aluminum heat sink for effective heat dissipation

• Various operating modes can be set depending on the racing class (stock, modified, off-road, drift, crawler)

• Space-saving electronic on/off switch integrated in the housing

• Dust and splash-proof

Programmable parameters

• Operating mode (forward only, forward-backward, forward-brake-backward)

• Reverse mode programmable in four power levels

• Undervoltage shutdown

• Overheating protection adjustable in 4 levels

• Braking mode (9 step Braking force, 4 step initial brake, 2 step brake line)

• Starting behavior (16 steps from soft to hard)

• Boost power & control behavior adjustable

• Turbo function individually configurable
