Scale: 1/8 Large Scale

  • Type: Crawler
  • Support Max Battery Size 150mmx46mmx40mm
  • Car Size: 670mm(L) x 302mm(W) x 307mm(H)
  • Car Structure: Portal Axle System
  • Wheel Base: 374mm
  • Wheel Track: 265mm
  • Minimum Underground Clearance: 45mm

Frame

  • Chassis frame: Multi-Connection design 1.2mm thickness formed steel
  • Suspension: Full Steel Metal Alloy front and rear straight axle / non-independent
  • Full Metal Portal Axle System (Support Front/Rear Diff Lock) with CNC Cover
  • Approach Angle: 65°
  • Passing Angle: 52°
  • Departure Angle: 49°
  • Shock Absorber: 90mm adjustable egative pressure full metal shock

Driving

  • 14T (Metal Gear), Support adjustable backlash to 12T - 20T
  • Driving: 2WD / 4WD / Front Drive / Rear Drive
  • All Metal Gears & Driver Axle
  • Integrated Transmission Gearbox
  • Include: 2 speed, 4WD, reverse transmission, front-drive, rear-drive, four output and other integrated gearbox
  • Tyre: 2.2inch All-terrain tyres (Mark Ma Authorisation) Aluminium Rim
  • Full size spare tyre with nylon rim

Power

  • MOTOR: Factory Stander RS775 Motor (Customised 18000RPM)
  • Support 540, 550 or 1:8 Brushless Motor (Diameter not more than 46mm Length not more than 75mm)
  • ESC: WP880 (BEC7.4V) (Customised high Voltage Splash proof ESC)
  • Battery: Not Included, Support 2S-4S Lithium Battery (XT60 Plug)
  • (Max Battery Size no more than 150mmx46mmx40mm)



REQUIRED TO COMPLETE
• Battery and charger
• Batteries for transmitter

SKU TH-FOUNDERPRO-G
Brand Traction Hobby
